Controlador de temperatura ambiente certificado CE con termostato de calefacción doméstico conectado al teléfono WiFi
El termostato de la serie HTW-WF17 ha sido desarrollado para controlar sistemas de calefacción por suelo radiante, calefacción por agua o calderas de agua/gas. Estas unidades están diseñadas para su uso en propiedades comerciales, industriales, civiles y domésticas.
Basic Info.
Product Description
Controlador de temperatura ambiente certificado CE con termostato de calefacción doméstico conectado al teléfono WiFi
>> General
El termostato de la serie HTW-WF17 ha sido desarrollado para controlar sistemas de calefacción por suelo radiante, calefacción por agua o calderas de agua/gas. Estas unidades están diseñadas para su uso en propiedades comerciales, industriales, civiles y domésticas.
>> Ordering Guide
|
HTW-WF17- ** |
Smart Wifi Thermostat |
|
|
Code |
Application |
|
|
-5A |
Water Heating, 3A, NC+NO+Com output terminals |
|
|
-16A |
Electric Underfloor Heating, 16A, L+N line voltage output terminals |
|
|
-NV |
Water/Gas Boiler, 3A, 1 pair of Non-Voltage output terminals |
|
|
e.g. HTW-WF17-5A refers to application:Water Heating, 5A, NC+NO+Com output terminals |
||
>> Specification
| Power Supply | 95~240Vac, 50/60Hz | Sensor | NTC3950, 10K |
| Current Load | 5A(-5A, -NV application) | Temperature Accuracy | ±0.5°C or ±1ºF |
| 16A(-16A application) | Set-Point Range | 5~35°C | |
| Storage Temp. | -10 ~ 45 °C | Display Temp. Range | 5 ~ 99°C |
| Power Consumption | < 1.5W | Timing Error | < 1% |
| Housing Material | PC +ABS ( Fireproof) | Installation Box | EU or Standard Electric Box |
| Protection Class | IP20 | Operating Buttons | Capacitive Touch Buttons |
Q1:What is the unit price?
A.:The unit price varies according to different specific requirements, we are more than pleased to quote you the best price once
get your specific application. e.g. W/O Modbus, W/O key-card, 2/4 pipe system, W/O customized programming...
Anyway, we are always ready to discuss details with you via Email.
Q2:What is the MOQ, small quantities accetaple?
A.: Commonly the MOQ for us is 500pcs, however, we also accept small quantities or Sample orders as starting.
Q3:How is your products' quality and warrenty?
A.:All of our products meet EU standards, samples are available for quality evaluation; all products are with 18 months warrenty.
Q4:Can I print my logo on the products, and customize my own designed packing?
A.:100% YES, but the order quantity shall be over MOQ, or else, extra costs will be charged.
Q5:Do you supply OEM or ODM?
A.:Yes, we have strong R&D sources and production ability, and already helping many international companies OEM/ODM cases with highly positive feedback.
Q6:Why should I buy products from your company?
A.:That's really a good question, Quality Products but with Competitive Price, Timely Delivery, Professional and Fast Reacton, ...
About Hotowell
Hotowell International Co., Limited is an innovative and modern medium-sized enterprise, the company is headquartered in Xiamen (China/Fujian),which is Chinese professional manufacturer of thermostats, zone valves, flow switches, other HVAC components ,etc. Supplying quality products at competitive prices.
