Termostato eléctrico para habitaciones con calefacción por suelo radiante con control de voz digital Google ALexa
Termostato eléctrico para habitaciones con calefacción por suelo radiante con control de voz digital Google ALexa Termostato eléctrico para habitaciones con calefacción por suelo radiante con control de voz digital Google ALexa Termostato eléctrico para habitaciones con calefacción por suelo radiante con control de voz digital Google ALexa Termostato eléctrico para habitaciones con calefacción por suelo radiante con control de voz digital Google ALexa

Termostato eléctrico para habitaciones con calefacción por suelo radiante con control de voz digital Google ALexa

Identificación del producto : HTW-HT03
Etiquetas del producto :
Atributos del producto :

El termostato Wifi de la serie HTW-HT03 se usa ampliamente en estos entornos, como casas, edificios residenciales,Escuelas, hoteles, hospitales, oficinas, etc. para mantener una temperatura ambiente ideal. Se puede utilizar en sistemas de calefacción por suelo radiante eléctrico, calefacción por agua o caldera de agua/gas.

Descripción del producto
Google ALexa Digital Voice Control Electric Floor Heating Room Thermostat
Product Description



>> General

El termostato Wifi de la serie HTW-HT03 se usa ampliamente en estos entornos, como casas, edificios residenciales, Escuelas, hoteles, hospitales, oficinas, etc. para mantener una temperatura ambiente ideal. Se puede utilizar en sistemas de calefacción por suelo radiante eléctrico, calefacción por agua o caldera de agua/gas.



>> Feature

* 47 idiomas principales sincronizados en la aplicación (inglés, español, ruso, húngaro, turco, hebreo, alemán, italiano, japonés, francés, polaco, chino simplificado, chino tradicional, holandés, portugués, vietnamita, árabe, coreano) * Fácil instalación a presión * Apto para caja eléctrica de unión estándar y de la UE * Trabaje fácilmente con Amazon alexa, Google Assitant, IFTTT. * Control de grupo en 1 aplicación

>> Ordering Guide

HTW-HT03- **
Smart Wifi Thermostat

Code
Application

-3A
Water Heating, 3A, NC+NO+Com output terminals

-16A
Electric Underfloor Heating, 16A, L+N line voltage output terminals

-NV
Water/Gas Boiler, 3A, 1 pair of Non-Voltage output terminals
e.g. HTW-HT03-3A refers to application:Water Heating, 3A, NC+NO+Com output terminals

>> Specifications

Power Supply
95~240Vac, 50/60Hz
Sensor
NTC3950, 10K

Current Load
3A(-3A, -NV application)
Temperature Accuracy
±0.5°C or ±1℉
16A(-16A application)
Set-Point Range
5~35°C
Storage Temp.
-5 ~ 45 °C
Display Temp. Range
5 ~ 99°C
Power Consumption
< 1.5W
Timing Error
< 1%
Housing Material
PC +ABS ( Fireproof)
Installation Box
EU or Standard Electric Box
Wires on Terminals
Wire 2 x 1.5 mm2 or 1 x 2.5 mm2
Protection Class
IP20
Operating Buttons
Capacitive Touch Buttons

>>  Dimensions and Display

>> Installation

* Make sure the power is OFF! Try turning ON your heating/cooling system by changing the temperature. If you can't get the system to turn ON in 5 minutes, you'll know the power is OFF.
* Take off the installation faceplate by grasping and gently pulling, then connect voltage supply/load output/external sensor(if with) wires respectively to appropriate terminals.
*  Fix the installation plate onto the electric junction box with screws packed in the box.
* Fasten the thermostat display part and the installation faceplate through the groove.(Installation process completed)

Applications

Company Profile

Hotowell is a high-tech company with rich experiences in product design and manufacturing, knowledge about global HVAC standards, and highly-trained team. Our objective is to produce and design user-friendly HVAC products on the highest technical level for improving people's experience in temperature/environment comfort.

Hotowell has been cooperating with many international companies and HVAC projects through Europe, American, Asia, Oceania. Our product range contains:
Thermostats, Motorized Zone Valves, Ball Valves, Valve Actuators, Damper Actuators, Controllers, Radiator valves, and etc. covering industrial, commercial and residential temperature controls.
