Válvula de bola motorizada de tres vías G3/4 de 24V, válvula motorizada de alta calidad, agua fría/agua caliente

Identificación del producto : HTW-MSB

Etiquetas del producto : Válvula de bola motorizada

Atributos del producto :

Las válvulas de bola motorizadas de la serie HTW-MSB se utilizan para controlar el encendido/apagado de la tubería del sistema de aire acondicionado de agua caliente/fría para controlar la temperatura ambiente. La válvula es accionada por un motor síncrono.

Descripción del producto

Product Description

Válvula de bola motorizada de tres vías G3/4 de 24V, válvula motorizada de alta calidad, agua fría/agua caliente

HTW-MSB Series Motorized Ball Valves are used to control the on/off of heat/cool water air-conditioning system pipe to control the room temperature. The valve is driven by synchronous motor. The motor connects with room thermostats by the terminal of common, open and close. By sampling and dealing with the site data, the thermostats send control signal to open/close the motor of ball valve. Then the heat/cool water enters into fan coil unit to supply the heat or cool air. When the room temperature reaches the set-point, thermostat will send a signal to cut off the ball valve and make it on the best status. Then the room temperature will keep in the comfortable range.
Valve thread size: G1/2,G3/4,G1,G1.1/4
Thread connection. Valve body could be installed first. Simple wiring. The actuator could be installed near to the wall.

>> Material
•Valve Body: Hpb59-1 (Gilded with Nickle) ;
•Valve Seal: Stem: EPDM with double O-ring ;
•Ball: PTFE+EPDM with double O-ring;
•Actuator enclosure: PC+10GF;
•Actuator revolving shaft: POM;

>> Specification

Actuator motor	Reversible synchronous motor
Power supply	AC220V, AC24V
Output torque	10N.m
Power consumption	<5W
Control way	on/off(SPDT)
Pipe Connection	G/BSP
Media temperature range	2°C~90°C
Ambient temperature	-5°C~60°C
Running time	16S/50Hz
Ambient humidity	<90%
Pressure grade	PN20
Protect rank	IP54
