Termostato de calefacción programable wifi inteligente con sensor externo para limitar la calefacción por suelo radiante
Termostato de calefacción programable wifi inteligente con sensor externo para limitar la calefacción por suelo radiante Termostato de calefacción programable wifi inteligente con sensor externo para limitar la calefacción por suelo radiante Termostato de calefacción programable wifi inteligente con sensor externo para limitar la calefacción por suelo radiante

Termostato de calefacción programable wifi inteligente con sensor externo para limitar la calefacción por suelo radiante

Identificación del producto : HTW-WF06
Atributos del producto :

El termostato Wifi de la serie HTW-WF06 se usa ampliamente en estos entornos, como hogares, edificios residenciales, escuelas, hoteles, hospitales, oficinas, etc., para lograr una temperatura ambiente ideal. Se puede utilizar en sistemas de calefacción por suelo radiante eléctrico, calefacción por agua o calderas de agua/gas.

Descripción del producto

Product Description



Termostato de calefacción programable wifi inteligente con sensor externo para limitar la calefacción por suelo radiante

>> General
HTW-WF06 series Wifi thermostat is widely used in these environment like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose. It can be used in Electric Underfloor Heating, Water Heating or Water/Gas Boiler systems.



>> Ordering Guide

>> Specifications

Power Supply
95~240Vac, 50/60Hz
Sensor
NTC3950, 10K

Current Load
3A (-3A, -NV application)
Temperature Accuracy
±0.5°C or ±1℉
16A (-16A application)
Set-Point Range
5~35°C
Storage Temp.
-5 ~ 45 °C
Display Temp. Range
5 ~ 99°C
Power Consumption
< 1.5W
Timing Error
< 1%
Housing Material
PC +ABS ( Fireproof)
Installation Box
EU or Standard Electric Box
Protection Class
IP20
Operating Buttons
Capacitive Touch Buttons
Wires on Terminals
Wire 2 x 1.5 mmor 1 x 2.5 mm2
Dimensions and Display
Company Profile


Hotowell has been cooperating with many international companies and HVAC projects through Europe, American, Asia, Oceania. Our product range contains:
Thermostats, Motorized Zone Valves, Ball Valves, Valve Actuators, Damper Actuators, Controllers, Radiator valves, and etc. covering industrial, commercial and residential temperature controls.
