Interruptor de caudal de líquido IP65 Control de caudal de agua

>> General

Interruptor de Medición de Alarma del Sensor de Flujo de Agua(HTW-AFS)

Controla y monitoriza el flujo de líquido de calderas, bombas, etc., de equipos de calefacción, refrigeración y aire acondicionado.


>> Features

Flow control of water and normal media
Renovated SPDT micro switch ensures the reliable switch function
15(8A) 250VAC switch rating
IP65, class I enclosure
Setpoint adjustable
Stainless steel paddle
Brass/S.S material
Max. liquid temp 120ºC
Max. working pressure:1.5Mpa


>> Specification

Type of operation                         On/Off, single-stage, micro switch

Output                                          SPDT  15(8A)  24/250Vac

Flow rates                                    See flow rate table

Flow rate setting adjustment       Internal srew

Sensing element                           Paddle

Liquid applications                        Hot, chilled, well, pool and sea water,

                                                     Brine or ethylene glycol

Parts material in contact with fluid    Brass

Paddle material                             Stainless steel

Liquid temperature                         -20C-120C

Permissible ambient temperature   -40C-85C

Permissible ambient humidity         10…90% RH, non-condensing

Cable entry                                       M18

Housing                                          Galvanized Steel Plate, ABS or PC cover

Protection                                      IP65

Color                                              White

Weight                                            1.0Kg
