Regulador de presión de agua de retorno por resorte de acero inoxidable Válvula motorizada de control de agua fría/caliente
Las válvulas motorizadas de la serie HTW-W27 se utilizan para controlar el flujo de agua caliente/agua fría, en aplicaciones de calefacción/refrigeración o aire acondicionado para controlar indirectamente la temperatura ambiente. Se compone de actuador y cuerpo de válvula. La válvula normalmente está cerrada. Cuando el termostato (con sensor NTC) transfiere una señal al actuador, que enciende la fuente de alimentación y luego abre la válvula que deja pasar agua caliente o fría a la unidad fancoil. Si la temperatura ambiente alcanza el punto de ajuste, el termostato transfiere una señal al actuador para cortar el suministro de energía y el retorno por resorte apaga la válvula y detiene el flujo de agua caliente o fría. Por lo tanto, la temperatura ambiente podría mantenerse como una temperatura constante a través de la válvula abierta o cerrada.
Regulador de presión de agua de retorno por resorte de acero inoxidable Válvula motorizada de control de agua fría/caliente
>> General
HTW-W27 Series Motorized Valves are used to control the flow of hot water/chilling water, in heating/cooling or air-conditioning applications so as to control room temperature indirectly. It consists of Actuator and Valve Body. The valve is normally closed. When thermostat(with NTC sensor)transfers a signal to actuator, which switch on power supply, and then opens valve letting hot water or chilling water to fan coil unit. If the room temperature reaches set-point, the thermostat transfers a signal to actuator to cut off the power supply and spring return switches the valve off, and stops the flow of hot or chilling water. Therefore, the room temperature could be kept as a constant temperature through valve opened or closed.
>> Characteristics & Materials
•Valve Body: Forged Brass
•Actuator plate: Stainless Steel
•Cover: Aluminum
•Valve Stem: Brass
•Single direction motorized drive, stainless steel spring return
•Configuration: Normally Closed Two-way and Diverting Three-way
•The power supply and connection type can be made as requested
•Actuator and Valve Body can be easily assembled and disassembled and installed without any tools
>> Technical parameters
•Power Supply: AC220V/AC110V/AC24V±10% 50/60Hz Optional
•Consumption: 6.5W•Compressive Strength: 1.6Mpa
•Valve Working Time:
•3-way valve: Opening Time:14~18s Closing Time:5~7s
•2-way Valve: Opening Time:8~12s Closing Time:3~5s
•Working Temperature: 5~40℃
•Pipe Water Temperature:5~90℃
>> Models & Specifications of Valve Body
>> Dimensions
>> Installation
