Heating Thermostat HTW-WF01 Tuya Support WIFI Room Temperature Controller
Heating Thermostat HTW-WF01 Tuya Support WIFI Room Temperature Controller Heating Thermostat HTW-WF01 Tuya Support WIFI Room Temperature Controller Heating Thermostat HTW-WF01 Tuya Support WIFI Room Temperature Controller Heating Thermostat HTW-WF01 Tuya Support WIFI Room Temperature Controller Heating Thermostat HTW-WF01 Tuya Support WIFI Room Temperature Controller

Heating Thermostat HTW-WF01 Tuya Support WIFI Room Temperature Controller

Product ID : HTW-WF01
Product Tags : Heating Thermostat
Product Attributes :

HTW-WF01 series Tuya Wifi thermostat is widely used in these environment like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose. It can be used in Electric Underfloor Heating, Water Heating or Water/Gas Boiler systems.

Product Description
Product Description



Heating Thermostat HTW-WF01 Tuya Support WIFI Room Temperature Controller




>> General
HTW-WF01 series Tuya Wifi thermostat is widely used in these environment like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose. It can be used in Electric Underfloor Heating, Water Heating or Water/Gas Boiler systems.



>> Ordering Guide

HTW-WF01- **


Code
Application
-3A
Water Heating, 3A, NC+NO+Com output terminals
-16A
Electric Underfloor Heating, 16A, L+N line voltage output terminals
-NV
Water/Gas Boiler, 3A, 1 pair of Non-Voltage output terminals
e.g. HTW-WF01-3A refers to application: Water Floor Heating, 3A, NC+NO+Com output terminals

>> Specifications

Power Supply
95~240Vac, 50/60Hz
Sensor
NTC3950, 10K

Current Load
Fan Relay 5A(-3A-inductive)
Temperature Accuracy
±0.5°C or ±1℉
Valve Relay 3A(1A -inductive)
Set-Point Range
5~35°C
Storage Temp.
-5 ~ 45 °C
Display Temp. Range
5 ~ 99°C
Power Consumption
< 1.5W
Timing Error
< 1%
Housing Material
PC +ABS ( Fireproof)
Installation Box
EU or Standard Electric Box
Protection Class
IP20
Operating Buttons
Capacitive Touch Buttons
Wires on Terminals
Wire 2 x 1.5 mmor 1 x 2.5 mm2
