WiFi Room Thermostat Multi-Stage Thermostat for Heat Pump System

Product ID : HTW-MT08

Product Tags : Room thermostat Thermostat heat pump thermostat

Product Attributes :

HTW-MT08 Series Single Multi-Stage Digital Heat Pump Thermostat is a device for indoor temperature control. It is mainly applied to heat pump system for heating/cooling, the device is of high reliability and practicability, and it can support up to 3H/2C system. This model is Max. 2H2C for conventional System or Max. 3H/2C for Heap Pump System.

Product Description

WiFi Room Thermostat Multi-Stage Thermostat for Heat Pump System

>> General


HTW-MT08 Series Single Multi-Stage Digital Heat Pump Thermostat is a device for indoor temperature control. It is mainly applied to heat pump system for heating/cooling, the device is of high reliability and practicability, and it can support up to 3H/2C system. This model is Max. 2H2C for conventional System or Max. 3H/2C for Heap Pump System.

>> Ordering Guide

HTW-MT08(-WWF/BWF/SWF)		Wi-Fi Version (White/Black/Brushed Cover)
HTW-MT08-BWF-AD		Black colour + Wi-Fi + With 4-5 wire adaptor

>> Specification

Voltage	24VDC/AC +10%	Current Load	1A (Inductive) 3A (Resistance)
Self-consumption	1.5W	Sensor	NTC3950, 10K
Set Temp. Range	41-95 ℉ (5~35℃)	Accuracy	1 ℉ (0.5℃）
Display Temp. Range	41~95 ℉ (5~35℃)	Material	PC+ABS(Fireproof)
Available Installation 1	Wall mounted
Available Installation 2	Distance of 62±5 mm (Europe, China and Japan)
Available Installation 3	Hole Distance of 86±3 mm (USA and Italy etc)
