Hotowell Bacnet FCU Hotel Central Aircon System Flat Mount Thermostat

Product ID : HTW--31-F10-4BK

Product Tags : Fan coil thermostat

Product Attributes :

This HTW-31-F10-4BK digital thermostat is designed to controls the fans, valves, dampers or electric heater in fan coil units andheating applications in industrial, commercial or residential
environment.

Product Description

Hotowell Bacnet FCU Hotel Central Aircon System Flat Mount Thermostat

>>General.

This HTW-31-F10-4BK digital thermostat is designed to controls the fans, valves, dampers or electric heater in fan coil units andheating applications in industrial, commercial or residential
environment.

>>Features.

• Attractive modern styling
• Adjustable heating/cooling/ventilating mode control
• Adjustable manual 3-speed and automatic fan speed control
• 4pipe system
• Bacnet
• Keycard Contact
• External sensor(Optional)

>>Technical Specification.

Power supply	110-230V
Frequency	50/60HZ
Control algorithm	Pl, On/off output
Accuracy	+/- 1°C at 21 °C
Backlight	White
Power Consumption	1.5A
Setpoint range	5~80℃
Ambient	0~50℃
Protection Class	IP30
Relative Humidity	85%
Housing	ABS to UL94-5 fire retardantplastic
