Fcu Thermostat Smart Thermostat with Keycard RS485 Room Thermostat
Product ID : HTW-FC08
Product Tags :
Fan coil thermostatRoom thermostatThermostatWifi thermostatair conditioner thermostathotel thermostatmodbus thermostatsmart thermostat
Product Attributes :
HTW-FC08 series smart fan coil thermostat is designed with EC Fan + 1 cool valve + 1 heat valve + externals sensor + Keycard + Modbus +WiFi communication functions, it is widely used in these environment like Homes,Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose.
Product Description
Fcu Thermostat Smart Thermostat with Keycard RS485 Room Thermostat
>> General
HTW-FC08 series smart fan coil thermostat is designed with EC Fan + 1 cool valve + 1 heat valve + externals sensor + Keycard + Modbus +WiFi communication functions, it is widely used in these environment like Homes,Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose.
>> Features
--EC fan control with starting voltage configurable
--Snap-In Easy Installation
-- Fit for EU & Standard Junction Electric Box
-- Modbus and WiFi Communication
-- 2/4 pipe system configurable
-- Fashion Sense of Science and Technology
-- Key-Card, External Sensor
-- Auto Heat/Cool Changeover
-- Internal and External sensor temperature readable from Modbus
>> Typica Wiring
>> Specification
| Power Supply | 85~250Vac, 50/60Hz | Sensor | NTC3950, 10K |
| Current Load | 0-10V Fan | Temperature Accuracy | ±0.5°C or ±1ºF |
| Valve Relay 0-10V Singal | Set-Point Range | 5~50°C | |
| Storage Temp. | -5 ~ 45 °C | Display Temp. Range | 0 ~ 60°C |
| Power Consumption | < 1.5W | Timing Error | < 1% |
| Housing Material | PC +ABS ( Fireproof) | Installation Box | Standard Electric Box |
| Product Dimension | 86 x 86 x 40 mm | ||
| Protection Class | IP20 | Operating Buttons | Capacitive Touch Buttons |
>> Dimensions and Display
