Electric Floor Heating System Thermostat Temperature Controller Factory Price
HTW-ECB6 series thermostat can be used in Electric Underfloor Heating, Water Heating or Water/Gas Boiler systems
Electric Floor Heating System Thermostat Temperature Controller Factory Price
>> General
HTW-ECB6-16A1
HTW-ECB6 series Wifi thermostat is widely used in environments like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices, etc. to maintain an ideal room temperature. It can be used in Electric Underfloor Heating, Water Heating or Water/Gas Boiler systems
>> Feature
* 17 Mainstreaming Languages synchronize in APP
* Snap-In Easy Installation
* Fit for EU & Standard Junction Electric Box
* Easily Work with Amazon alexa, Google Assitant
* Group Control in 1 App
* Fashion Sense of Science and Technology
>> Ordering Guide
| HTW-ECB6- ** |
Code |
Application |
|
-3A |
Water Heating, 3A, NC+NO+Com output terminals |
|
|
-16A |
Electric Underfloor Heating, 16A, L+N line voltage output terminals |
|
|
-NV |
Water/Gas Boiler, 3A, 1 pair of Non-Voltage output terminals |
|
|
e.g. HTW-ECB6-3A refers to application:Water Heating, 3A, NC+NO+Com output terminals |
||
>> Specification
| Power Supply | 95~240Vac, 50/60Hz | Sensor | NTC3950, 10K |
| Current Load | 3A(-3A, -NV application) | Temperature Accuracy | ±0.5°C or ±1ºF |
| 16A(-16A application) | Set-Point Range | 5~35°C | |
| Storage Temp. | -5 ~ 45 °C | Display Temp. Range | 5 ~ 99°C |
| Power Consumption | < 1.5W | Timing Error | < 1% |
| Housing Material | PC +ABS ( Fireproof) | Installation Box | EU or Standard Electric Box |
| Protection Class | IP20 | Operating Buttons | Capacitive Touch Buttons |
>> Dimensions and Display
