Brass Motorized Check Valve 2 Way 3 Way SPDT Electric Motorized Valve
Brass Motorized Check Valve 2 Way 3 Way SPDT Electric Motorized Valve Brass Motorized Check Valve 2 Way 3 Way SPDT Electric Motorized Valve Brass Motorized Check Valve 2 Way 3 Way SPDT Electric Motorized Valve Brass Motorized Check Valve 2 Way 3 Way SPDT Electric Motorized Valve Brass Motorized Check Valve 2 Way 3 Way SPDT Electric Motorized Valve

Brass Motorized Check Valve 2 Way 3 Way SPDT Electric Motorized Valve

Product ID : HTW-V61
Product Tags : Motorized Zone Valve
Product Attributes :

HTW-V61 Series Motorized Valves are used to control the flow of hot water, chill water through the fan coil unit in heating, cooling or air-conditioning applications, so as to control room temperature indirectly. When thermostat sends the controlling signal to the motorized valve, the valve is opened with water flowing, and when the signal disappears, the valve, with the help of its own spring, returns back to its original place to close the valve so as to stop the water flow.

Product Description
Brass Motorized Check Valve 2 Way 3 Way SPDT Electric Motorized Valve
Product Description

>> General





HTW-V61 Series Motorized Valves are used to control the flow of hot water, chill water through the fan coil unit in heating, cooling or air-conditioning applications, so as to control room temperature indirectly. When thermostat sends the controlling signal to the motorized valve, the valve is opened with water flowing, and when the signal disappears, the valve, with the help of its own spring, returns back to its original place to close the valve so as to stop the water flow





>> Specification

Type
Model
DN(mm)
Inner Screw
Thread (G)
Dimension(mm)
L
H
2-Way
HTW-V61-215
15
1/2"
90
114
HTW-V61-220
20
3/4"
95
116
HTW-V61-225
25
1"
105
128
3-Way
HTW-V61-315
15
1/2"
90
133
HTW-V61-320
20
3/4"
95
133
HTW-V61-325
25
1"
105
144

>>Wiring Diagram

>> Dimensions
