 Hotowell Model Air Conditioning 3- Way Motorized Control Valve
 Hotowell Model Air Conditioning 3- Way Motorized Control Valve  Hotowell Model Air Conditioning 3- Way Motorized Control Valve  Hotowell Model Air Conditioning 3- Way Motorized Control Valve  Hotowell Model Air Conditioning 3- Way Motorized Control Valve  Hotowell Model Air Conditioning 3- Way Motorized Control Valve

Hotowell Model Air Conditioning 3- Way Motorized Control Valve

Product ID : HTW-V61
Product Tags :
Product Attributes :

HTW-V61 series motorized valves are used to control the flow of hot water, chill water in heating, cooling or air-conditioning applications, so as to control room temperature indirectly. It consists of Actuator and Valve Body. The room temperature could be controlled in the set-point through turn-on or turn-off of valve.

Product Description
Product Description

>> General

HTW-V61 series motorized valves are used to control the flow of hot water, chill water in heating, cooling or air-conditioning applications, so as to control room temperature indirectly. It consists of Actuator and Valve Body. The room temperature could be controlled in the set-point through turn-on or turn-off of valve.

>> Models & Specifications of Actuator

Model Rated Power Supply
HTW-V61-8503 AC220V±10%, 50/60Hz
HTW-V61-8203 AC110V±10%, 50/60Hz
HTW-V61-8003 AC24V±10%, 50/60Hz

>Models & Specifications of Valve Body

Model
Configuration
Kvs
Connection Type
HTW-V61-215
normally closed two-way
2
G1/2
HTW-V61-220
normally closed two-way
3.2
G3/4
HTW-V61-225
normally closed two-way
5.7
G1
HTW-V61-315
mixing three-way
3.2
G1/2
HTW-V61-320
mixing three-way
4.6
G3/4
HTW-V61-325
mixing three-way
4.8
G1

>> Technical parameters

• Consumption 5W
•Drive style Bi-direction reversible motor drive
•Cooperate time with thermostat the valve open within 6s at 60HZ
•N.W.(Kg)-Actuator 0.35
•Medium Cool/hot water
•Liquid temperature 1~95°C
•Pressure(MPa) 1.6
•Environment temperature 0~65°C the max relative humidity, non-condensing
•Storage temperature -20~65°C the max relative humidity, non-condensing

>> Wring Diagram

>> Dimensions

>> Installation
