Large LCD Display Room Under Tile Water Heating Universal Thermostat
•Attractive and Big LCD Display
•Adjustable Comfort, Energy-saving and Prog. mode control
•Electric Heating System(Max.16A)
Water Heating System(Max.3A)
•7 days Programmable (5+1+1)
•Clock
•RS485 RTU Modbus Communication
•86*86 mm/55mm*50mm EU Junction Box Mounting
>> General
Programmable Radiator/Underfloor Heating Thermostat-HTW-31-H17 series are used to control room temperature in commercial,industrial and residential environment via controlling fan coil units and motorized zone valves, motorized fan and valves of heating/cooling central air-condition and system thereof,and uses NTC to detect the room temperature and compares it with desired setpoint so as to maintain the correct temperature.
>>Features
•Attractive and Big LCD Display
•Adjustable Comfort, Energy-saving and Prog. mode control
•Electric Heating System(Max.16A)
Water Heating System(Max.3A)
•7 days Programmable (5+1+1)
•Clock
•RS485 RTU Modbus Communication
•86*86 mm/55mm*50mm EU Junction Box Mounting
>>Technical parameters
Power Supply - 100~240Vac, 50/60Hz | Backlight - Blue |
Power Consumption - 1 A | Sensor - NTC 3950, 10K ohms at 25℃ |
Set Point Range - 5~35℃ | Accuracy - ±0.5 ℃ (step control by +0.5℃) |
Ambient - 0~50℃ | Protection Class - IP30 |
Relative Humidity - 85% | Housing - ABS to UL94-5 fire retardant plastic |
>>Display and Buttons
>>Installation
>>Wiring Diagram
>> Company Profile
Hotowell is a high-tech company with rich experiences in product design and manufacturing, knowledge about global HVAC standards, and highly-trained team.
Our objective is to produce and design user-friendly HVAC products on the highest technical level for improving people's experience in temperature/environment comfort.
Hotowell has been cooperating with many international companies and HVAC projects through Europe, American, Asia, Oceania. Our product range contains:
Thermostats, Motorized Zone Valves, Ball Valves, Valve Actuators, Damper Actuators, Controllers, Radiator valves, and etc.
covering industrial, commercial and residential temperature controls.
>> FAQs
Q1:What is the unit price?
A.:The unit price varies according to different specific requirements, we are more than pleased to quote you the best price once get your specific application. e.g. W/O Modbus, W/O key-card, 2/4 pipe system, W/O customized programming...
Anyway, we are always ready to discuss details with you via Email.
Q2:What is the MOQ, small quantities accetaple?
A.: Commonly the MOQ for us is 500pcs, however, we also accept small quantities or Sample orders as starting.
Q3:How is your products' quality and warrenty?
A.:All of our products meet EU standards, samples are available for quality evaluation; all products are with 18 months warrenty.
Q4:Can I print my logo on the products, and customize my own designed packing?
A.:100% YES, but the order quantity shall be over MOQ, or else, extra costs will be charged.
Q5:Do you supply OEM or ODM?
A.:Yes, we have strong R&D sources and production ability, and already helping many international companies OEM/ODM cases with highly positive feedback.
Q6:Why should I buy products from your company?
A.:That's really a good question, Quality Products but with Competitive Price, Timely Delivery, Professional and Fast Reacton, ...
In a word, WE ARE DIFFERENT, why not just try from the Email...
