HTW-EW002 Noise Free Split Thermostat Modbus Connection 3 Fan Speed Complete HVAC Solution

Product ID : HTW-EW002

Product Tags : Hotel Occupancy System

Product Attributes :

HTW-EW002 is a Noise-Free room climate controller application for water-installation with fan coils/EC fan
/Modulating valve. It is designed as a RTU Modbus communicated device to operate the fan coil unit / EC Fan / Modulating Valve of a zone and includes a set of functions for lighting control, zone occupancy and window position based climate control. A high level of comfort and appropriate climate control to ensure maximum energy savings are thus provided.

Product Description

HTW-EW002 Noise Free Split Thermostat Modbus Connection 3 Fan Speed Complete HVAC solution

>> General

HTW-EW002 is a Noise-Free room climate controller application for water-installation with fan coils/EC fan
/Modulating valve. It is designed as a RTU Modbus communicated device to operate the fan coil unit / EC Fan / Modulating Valve of a zone and includes a set of functions for lighting control, zone occupancy and window
position based climate control. A high level of comfort and appropriate climate control to ensure maximum energy savings are thus provided.

These two parts are communicated via 3-wire with carrier transmission technology connections, up to 50m non- loss communication:
-GND
-12V
-DATA

>> Features

* AC controlling solutions	* Configurable for 2 pipe / 4 pipe systems
* Black-Negative/White-LCD screen Optional	* Black-Negative/White-LCD screen Optional
* Touch Key Pads:+T/-T/Setting/Fan speed/Model/On-Off	* Configurable max/min/economy temperature set points
* Completely flat tempered glass screen-protect cover	* Configurable anti-humidity requency:10/30,5/30,5/60
* Keycard/Window Card switch contact	* Automatic device startup after loss of power
* ON/Off 3 speeds / 1 speed configurable	* Configurable NO/NC valve outputs
* EC fan Control with starting/max. voltage configurable	* Delayed switching to Economy when card is removed
* Modulating Valve Output 0-10V / 2-10V configurable	* Switching Differential Dead Band configurable
