HTW-EG200 Series Motorized BanT V alves are used to control the on/off of heat/cool water air-conditioning system pipe to control the room temperature. The valve is driven by synchronous motor.
The motor connects with room thermostats by the terminal of common, open and close.
By sampling and dealing with the site data, the thermostats send control signal to open/close the
motor of ball valve.
Then the heat/cool water enters into fan coil unit to supply the heat or cool air.When the room temperature reaches the set-point, thermostat will send a signal to cut off the ball valve and make it on the best status.
Then the roomtemperature will keep in the comfortable range. Valve thread size: G1/2. G3/4. G1. G1.1/4
Air Conditioning Heat/Cool Water Control Elecrtic Ball Valve HTW-EG 2-3 way 1/2''-1 1/4'' Brass Valve
1. General
2. Specifications
Actuator motor | Reversible synchronous motor | Media temperature range | 2°C~90°C |
Power supply | AC220V, AC110V, AC24V | Running time | 16S/50Hz, 12S/60Hz |
Output torque | 3.5N.m | Power consumption | <5W |
Control way | on/off or 3-piont | Pipe Connection | G/BSP |
Ambient temperature | -5°C~60°C | Ambient humidity | <90% |
Pressure grade | PN20 | Protect rank | IP54 |
3. Model Comparison Table
4. Wiring Diagram
