Hotowell Heating Thermostat HTW-HT03 Series.pdf
>> General
HTW-HT03 series Wifi thermostat is widely used in these environment like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose. It can be used in Electric Underfloor Heating, Water Heating or Water/Gas Boiler systems. HTW-HT03-3A WiFi remote control thermostat is designed to open or close motorized valve in water floor heating system to maintain room temperature in confortable range. In water floor heating system, there is a taboo when install valve as below: The main materials, equipment and products used in construction lack technical quality appraisal documents or product qualification certificates that meet current standards.
Consequences: The quality of the project is unqualified, there are hidden dangers of accidents, it cannot be delivered on time, and must be reworked and repaired; it causes delays in the construction period and increases the input of labor and materials.
Measures: The main materials, equipment and products used in water supply and drainage and heating and sanitation projects should have technical quality appraisal documents or product qualification certificates that meet the current standards issued by the state or ministry; their product names, models, specifications, and national quality standards should be indicated Code, date of manufacture, name and location of manufacturer, inspection certificate or code of factory product.
>> Features
* 17 Mainstreaming Languages synchronize in APP(English, Spanish, Russian, Hungarian,Turkey, Hebrew, German, Italian, Japanese, French,Poland, simplified Chinese, traditional Chinese, Holland, Portuguese, Vietnamese, Arabic, Korean)
*Snap-In Easy Installation
*Fit for EU & Standard Junction Electric Box
*Easily Work with Amazon alexa, Google Assitant, IFTTT.
*Group Control in 1 App
*Fashion Sense of Science and Technology
>> Specification
| Power Supply | 95~240Vac, 50/60H | Sensor | NTC3950, 10k |
| Current Load | 3A(-3A, -NV application),16A(-16A application) | Temperature Accuracy | ±0.5°C |
| Set-Point temperature Range | 5~35°C | Storage Temp. | -5 ~ 45 °C |
| Display Temp. Range | 5 ~ 99°C | Power Consumption | < 1.5W |
| Housing Material | PC +ABS ( Fireproof) | Installation Box | EU or Standard Electric Box |
| Wires on Terminals | Wire 2 x 1.5 mm2 or 1 x 2.5 mm2 | Protection Class | IP20 |
>>Wiring Diagram
>> Thermostat Installation
nMake sure the power is OFF! Try turning ON your heating/cooling system by changing the temperature. If you can’t get the system to turn ON in 5 minutes, you’ll know the power is OFF.
nTake off the installation faceplate by grasping and gently pulling, then connect voltage supply/load output/external sensor(if with) wires respectively to appropriate terminals.
nFix the installation plate onto the electric junction box with screws packed in the box.
nFasten the thermostat display part and the installation faceplate through the groove.(Installation process completed)
>> Company Profile
>> FAQs
|
Q1: Do you supply OEM or ODM? |
|
A: Yes, we have strong R&D sources and production ability, and already helping many international companies OEM/ODM cases with highly positive feedback. |
|
Q2: Which payments are acceptable? |
|
A: We accept T/T,Paypal,Western Union. |
|
Q3: How fast can I get the quotation? |
|
A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us +86 0592 6538262 or tell us in your email so that we will regard your inquiry priority. |
|
Q4: What’s your production time? |
|
A:Usually production time is 15 to 20 days for quantity below 5,000pcs.
|
