Fireproof Housing Programmable Temperature Controller Heating Room Thermostat

Product ID : HTW-WF17

Product Tags : Heating Thermostat Room thermostat Wifi thermostat smart thermostat

Product Attributes :

The HTW-WF17 Series thermostat has been developed to control electric underfloor, water heating or water/ gas boiler systems.

Product Description

Fireproof Housing Programmable Temperature Controller Heating Room Thermostat

>> General
HTW-WF17
The HTW-WF17 Series thermostat has been developed to control electric underfloor, water heating or water/ gas boiler systems. These units are designed for use in commercial, industrial, civil, and domestic properties.

>> Specifications

Power Supply	95~240Vac, 50/60Hz	Sensor	NTC3950, 10K
Current Load	5A(-5A, -NV application)	Temperature Accuracy	±1°C
Current Load	16A(-16A application)	Set-Point Range	5~35°C
Storage Temp.	-10 ~ 45 °C	Display Temp. Range	5 ~ 99°C
Power Consumption	< 1.5W	Timing Error	< 1%
Housing Material	PC +ABS ( Fireproof)	Installation Box	EU or Standard Electric Box
Protection Class	IP20	Operating Buttons	Capacitive Touch Buttons
Wires on Terminals	Wire 2 x 1.5 mm2 or 1 x 2.5 mm2

Ordering Guide

HTW-WF17- **	Code	Application
	-3A	Water Heating, 3A, NC+NO+Com output terminals
	-16A	Electric Underfloor Heating, 16A, L+N line voltage output terminals
	-NV	Water/Gas Boiler, 3A, 1 pair of Non-Voltage output terminals
e.g. HTW-WF17-3A refers to application: Water Floor Heating, 3A, NC+NO+Com output terminals
