Room Thermostat Control 0-10V Valve Temperature Controller Thermostat Horizontal Direction

Product ID : HTW-T6865

Product Tags : Room thermostat Temperature thermostat smart thermostat

Product Attributes :

T6865 series thermostats are designed for the application of a 3-speed fan and modulating valves in a fan coil system.

Product Description

Room Thermostat Control 0-10V Valve Temperature Controller Thermostat Horizontal Direction

>> General

T6865 series thermostats are designed for the application of a 3-speed fan and modulating valves in a fan coil system. There are four sub-models according to the different functions and backlight, that could meet different requirements accordingly. Please confirm the right model based on your needs or contact us directly.

>> Ordering Guide

Model	Direction	Backlight	2 pipe	Power	Feature
T6865H2WB-M	Horizontal	Blue	2 pipe	24Vac	Remote Setback(Keycard)
T6865H2WG-M		Green			Remote Setback(Keycard)
T6865H2WB-R		Blue			External Sensor
T6865H2WG-R		Green			External Sensor

>> Specification

Power supply		24(+/-10%)VAC
Frequency		50Hz
Control algorithm		Pl, modulating output
Accuracy		+/- 1°C at 21 °C
Relay life		100,000 times
Setpoint range		10-32°C
Display range		0-37°C
Installation		Installed on 86x86mm junction box or 3x3 inch box
Protection Class		IP20
Environmental		Operation temperature: -18~49°C
