Smart Hotel Energy Saver Air Conditioning Lighting Control System
Key Card Smart Hotel Room Access System Controller Energy Saver Solutions (HTW-61-ES6201) is designed to control electrical consumption by detecting occupied/unoccupied presence, in order to connect/disconnect the air conditioning equipment and lighting automatically when the customer accesses or leaves the room.
Smart Hotel Energy Saver Air Conditioning Lighting Control System
General
Key Card Smart Hotel Room Access System Controller Energy Saver Solutions (HTW-61-ES6201) is designed to control electrical consumption by detecting occupied/unoccupied presence, in order to connect/disconnect the air conditioning equipment and lighting automatically when the customer accesses or leaves the room.
PIR presence detector operating algorithm
HTW-61-ES6201 has 1 input (E1) for a magnetic room contact placed on the doorframes of the room;
1 input (E2) for a magnetic window contact placed on the window frames.
3 inputs(E3,E4,E5) for PIR presence detectors.
When the door of the room is open, the energy saving system is activated instantly, and feed the following three outputs:
S1-Air-conditioning output with anti-humidity mode;
S2-Air-conditioning/Lighting output with delay time;
S3-Lighting output with delay time;
Once the door is closed, the system will try to determine if there is movement within 3s~T4 in the room
Magnetic window contact operating algorithm
If a magnetic window contact switch is connected to the terminals 12-13, when the contact is open, the output S1 will disconnect after 1min, until closing window contact again.
Typical Wiring Diagram
