2022 Residential 24 volt 2 stage furnace/heat pump thermostat for america

Product ID : HTW-81-FN7
Product Attributes :

HTW-81-FN7 Series Single Multi-Stage Digital Heat Pump Thermostat is a device for indoor temperature control. It is mainly applied to heat pump system for heating/cooling, with 3 modes easily switchable: Schedule, Hold and Holiday. The device is of high reliability and practicability,and it can support up to 3H/2C system.

Product Description

2022 Residential 24 volt 2 stage furnace/heat pump thermostat for america

>>Features

 Elegant design with 4.3” LCD display

 Individual programming Schedules:7 days*4 time periods

 Tempered glass panel with capacitive touch buttons

 NTC thermistor

>>Specification

>>Power supply: AC24V, 50Hz

>>Power dissipation:2W Dimension: 136*94*26mm Output: <1A (Resistant load)

>>Temperature range: 41ºF -99ºF (5ºC -37ºC)

>>Display accuracy: ±0.5 ºC

>>Wiring: Terminals

 >>Installation dimension: 60mm / 82mm (hole pitch)

>>Application
 >>1H/1C (conventional)
 >>1H/2C (conventional)
 >>2H/2C (conventional)
 >>2H/1C (conventional)
 >>1H/1C (heat pump)
 >>2H/1C (heat pump)
 >>2H/2C (heat pump)
 >>3H/2C (heat pump)

>>Wiring Diagram

Wiring Diagram.jpg

>>Terminal Instruction



Terminal Instruction.jpg

>>Controlling Type Configuration



Controlling type.jpg
