Home Products Hotowell Products CE Certificated Room Thermostat for Floor Heating System Smart Wifi Thermostat with Voice Control
CE Certificated Room Thermostat for Floor Heating System Smart Wifi Thermostat with Voice Control
CE Certificated Room Thermostat for Floor Heating System Smart Wifi Thermostat with Voice Control CE Certificated Room Thermostat for Floor Heating System Smart Wifi Thermostat with Voice Control CE Certificated Room Thermostat for Floor Heating System Smart Wifi Thermostat with Voice Control CE Certificated Room Thermostat for Floor Heating System Smart Wifi Thermostat with Voice Control CE Certificated Room Thermostat for Floor Heating System Smart Wifi Thermostat with Voice Control

CE Certificated Room Thermostat for Floor Heating System Smart Wifi Thermostat with Voice Control

Product ID : HTW-WF11
Product Attributes :

HTW-WF11 series Wi-Fi thermostat is widely used in these environments like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose. It can be used in Electric Underfloor Heating, Water Heating or Water/Gas Boiler systems.

Product Description

CE Certificated Room Thermostat for Floor Heating System Smart Wifi Thermostat with Voice Control



>> General

HTW-WF11 series Wi-Fi thermostat is widely used in these environments like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose. It can be used in Electric Underfloor Heating, Water Heating or Water/Gas Boiler systems.



>> Feature



* Fashion Sense of Science and Technology
* Reduces the costs saving by only heating and cooling your home when it's necessary.
* Allows you to adjust your home's temperature at anytime and anywhere.
* You can set up the whole week's temperature with your personal ideas.
* Extends the life of your HVAC system by alerting you when it's time to perform key maintenance tasks.



>> Specifications

Power Supply
95~240Vac, 50/60Hz
Sensor
NTC3950, 10K

Current Load
3A(-3A, -NV application)
Temperature Accuracy
±0.5°C or ±1℉
16A(-16A application)
Set-Point Range
5~35°C
Storage Temp.
-5 ~ 45 °C
Display Temp. Range
5 ~ 99°C
Power Consumption
< 1.5W
Timing Error
< 1%
Housing Material
PC +ABS ( Fireproof)
Installation Box
EU or Standard Electric Box
Wires on Terminals
Wire 2 x 1.5 mm2 or 1 x 2.5 mm2
Protection Class
IP20
Operating Buttons
Capacitive Touch Buttons

>> Typical Wiring

HTW-WF11- **
Smart Wifi Thermostat

Code
Application

-3A
Water Heating, 3A, NC+NO+Com output terminals

-16A
Electric Underfloor Heating, 16A, L+N line voltage output terminals

-NV
Water/Gas Boiler, 3A, 1 pair of Non-Voltage output terminals
e.g. HTW-WF11-3A refers to application:Water Heating, 3A, NC+NO+Com output terminals
Dimensions
Certifications
Packing & Shipping
