Smart Thermostat Heating cable thermostat with WIFI control room temperature and thermal protection

Smart Thermostat Heating cable thermostat with WIFI control room temperature and thermal protection

Product ID : HTW-WF02

Product Tags : modbus thermostat smart thermostat underfloor heating thermostat

Product Attributes :

HTW-WF02-FC series thermostat is widely used in these environment like Homes, Residential buildings,Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose.

Product Description

 Smart Thermostat Heating cable thermostat with WIFI control room temperature and thermal protection

>> Ordering Guide

HTW-WF02-FC-**	-2	2 pipe(tube) system
FCU Room Thermostat	-4	4 pipe(tube) system
	-M	0~10V Modulating Valve Output
	-N	RS485 Modbus RTU communication
	-K	Key Card occupancy input
	-W	WiFi Connection
	-T	Real Time Clock
	-P	Programmable
	-E	External Temperature Sensor
	-24v	Power Supply with 24Vac
e.g. HTW-WF02-FC-2KP refers to application: 2 pipe(tube) system, 3 fan speed + 1 H/C valve, with key card and weekly programmable

>> General
HTW-WF02 series thermostat is widely used in these environment like Homes, Residential buildings,Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose.

>>Features
-- 17 Mainstreaming Languages synchronize in APP(English, Spanish, Russian, Hungarian, Turkey, Hebrew, German, Italian, Japanese, French, Poland, simplified Chinese, traditional Chinese, Holland, Portuguese, Vietnamese, Arabic, Korean) -- Snap-In Easy Installation --  Fit for EU & Standard Junction Electric Box -- Easily Work with Amazon Echo, Google Home, Tmall Genie, IFTTT -- Group Control in 1 App --  Fashion Sense of Science and Technology

>> Specifications

Power Supply	95~240Vac, 50/60Hz	Sensor	NTC3950, 10K
Current Load	Fan Relay 5A(3A-inductive)	Temperature Accuracy	±0.5°C or ±1℉
Current Load	Valve Relay 3A(1A-inductive)	Set-Point Range	5~35°C
Storage Temp.	-5 ~ 45 °C	Display Temp. Range	5 ~ 99°C
Power Consumption	< 1.5W	Timing Error	< 1%
Housing Material	PC +ABS ( Fireproof)	Installation Box	EU or Standard Electric Box
Wires on Terminals	Wire 2 x 1.5 mm2 or 1 x 2.5 mm2
Protection Class	IP20	Operating Buttons	Capacitive Touch Buttons

Why Choose Us

Company Profile


Hotowell has been cooperating with many international companies and HVAC projects through Europe, American, Asia, Oceania.  Our product range contains:
Thermostats, Motorized Zone Valves, Ball Valves, Valve Actuators, Damper Actuators, Controllers, Radiator valves, and etc. covering industrial, commercial and residential temperature controls.
