Smart Wifi Thermostat control 3A water radiant heating and 2 pipe FCU system

Smart Wifi Thermostat control 3A water radiant heating and 2 pipe FCU system

Product ID : HTW-WF11-3AFC

Product Tags : smart thermostat

Product Attributes :

HTW-WF11-FC series Smart Wifi fan coil thermostat is widely used in these environment like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose.

Product Description

Smart Wifi Thermostat control 3A water radiant heating and 2 pipe FCU system

>> Ordering Guide

HTW-WF11-FC-**	-2	2 pipe(tube) system
FCU Room Thermostat	-4	4 pipe(tube) system
	-M	0~10V Modulating Valve Output
	-N	RS485 Modbus RTU communication
	-K	Key Card occupancy input
	-W	WiFi Connection
	-T	Real Time Clock
	-P	Programmable
	-E	External Temperature Sensor
	-24v	Power Supply with 24Vac
e.g. HTW-WF11-FC-2KP refers to application: 2 pipe(tube) system, 3 fan speed + 1 H/C valve, with key card and weekly programmable

>> Specifications

Power Supply	95~240Vac, 50/60Hz	Sensor	NTC3950, 10K
Current Load	Fan Relay 5A(3A-inductive)	Temperature Accuracy	±0.5°C or ±1℉
Current Load	Valve Relay 3A(1A-inductive)	Set-Point Range	5~35°C
Storage Temp.	-5 ~ 45 °C	Display Temp. Range	5 ~ 99°C
Power Consumption	< 1.5W	Timing Error	< 1%
Housing Material	PC +ABS ( Fireproof)	Installation Box	EU or Standard Electric Box
Wires on Terminals	Wire 2 x 1.5 mm2 or 1 x 2.5 mm2
Protection Class	IP20	Operating Buttons	Capacitive Touch Buttons

Details Images

Company Profile

Packing & Shipping

 Packing details

Unit Weight: 0.25KG/PC;
50 PCS/CTN;
Gross Weight: 13.5KG;
Paper box packing;
Box dimension: 52*24*33CM
Delivery time : Shipped in 15-20 days after payment

Our Service

Customer Service
1. OEM & ODM service offered2. sample's fee can be refunded after order reached 2000pcs

Warranty
1. Test the products one by one before delivery
2. We guarantee 18months from the date you get the goods,excludes damaged by human
3. If you can find out the problem and fix it easily, we will offer several components for service
