IP54 Protection Automatic Water Flow Switch Liquid Flow Switch
Product ID : HTW-F61KB
Product Tags :
Water Flow Switch
Product Attributes :
HTW-F61 Liquid Flow Switches are Single - Pole, Double - Throw (SPDT) flow switches that are used in liquid lines carrying water,ethylene glycol,or other liquids not classified as hazardous, They can be wired to energize one device and de-energize an other device powered from the same source when liquid flow either exceeds or drops below the set flow rate.
Product Description
IP54 Protection Automatic Water Flow Switch Liquid Flow Switch
>> General
HTW-F61 Liquid Flow Switches are Single - Pole, Double - Throw (SPDT) flow switches that are used in liquid lines carrying water,ethylene glycol,or other liquids not classified as hazardous, They can be wired to energize one device and de-energize an other device powered from the same source when liquid flow either exceeds or drops below the set flow rate.
>> Features
Maximum Liquid Pressure: 150psig(1034kPa)
Minimum Liquid Temperature: 32°F(0ºC)
Maximum Liquid Tempreature: 250°F(121ºC)
Electrical Ratings: 120VAC 208VAC 240VAC 277VAC
Pilot Duty: 125VA at 24/277VAC
Wiring Connection: Screw Type Terminals
Pipe Connector: 1 in. 11-1/2 NPT Threads
>> Specification
