Hotowell Temperature Controller Heating Controller Wifi Thermostat Digital Room Thermostat

Hotowell Temperature Controller Heating Controller Wifi Thermostat Digital Room Thermostat

Product ID : HTW-WF05

Product Tags :

Product Attributes :

HTW-WF05 is suitable for electric heating, water heating, wall-hung boilers and boiler-temperature control systems.It can be used in smart controlling hourses, shopping malls, and industrial places.

Product Description

Overview

Essential details

Warranty:: 2 years

After-sale Service:: Online technical support, Return and Replacement

Material:: Anti-flammable PC +ABS

Project Solution Capability:: total solution for projects

Application:: Apartment

Design Style:: Modern

Place of Origin:: Fujian, China

Brand Name:: Neutral

Model Number:: HTW-WF05

Type:: Floor Heating Parts

Floor Heating Part Type:: Floor Heating Thermostats

Power Supply::: 95~240Vac, 50/60Hz

Power Consumption::: <1.5W

Temperture Accurancy::: ±0.5°C or ±1℉

Timing Error::: <1%

Storage Temp.::: -5 ~ 45 °C

Installation Box::: European 60mm Round Box

Operating Buttons::: Capacitive Touch Buttons

Protection Class::: IP20

Housing Material::: PC +ABS ( Fireproof)

Certification:: ce

Packaging & delivery

Packaging Details

1pcs/box, 50pcs/carton

Port

xiamen

Picture Example:

Lead time:

Quantity(pieces)	1 - 500	501 - 1000	>1000
Est. time (days)	14	25	To be negotiated

Product Description

Hotowell Heating Controller Wifi Thermostat Digital Room Thermostat Temperature Controller

>> General
HTW-WF05 is suitable for electric heating, water heating, wall-hung boilers and boiler-temperature control systems.It can be used in smart controlling hourses, shopping malls, and industrial places.


>> Ordering Guide

HTW-WF05- **
	Code	Application
	-3A	Water Heating, 3A, NC+NO+Com output terminals
	-16A	Electric Underfloor Heating, 16A, L+N line voltage output terminals
	-NV	Water/Gas Boiler, 3A, 1 pair of Non-Voltage output terminals
e.g. HTW-WF05-3A refers to application: Water Floor Heating, 3A, NC+NO+Com output terminals

>> Specifications

<td style="margin: 0px; padding: 0px; font-style: inherit; font-variant: inherit; font-stretch: inherit; line-height: inherit; font-family: inherit; float: none; overflow: hidden

Power Supply	95~240 V AC，50~60 Hz	Current Load	5 A(water heating/water boiler/gas boiler) 16 A(electric heating)
Temp. Error	±1℃	Sensor	NTC3950,10K
Screen	LCD Negative display	Timing Error	<1%
Set Temp. Range	5～45℃	Power consumption	<1.5W
Working Ambient Temp/Humidity	0～45℃，5～95% RH (Non Condensing)	Installation Box	European 60mm Round Box
