HVAC Automation System Electric Thermal Expansion Actuator 24V/110V/220V Optional
Product ID : TAV01
Product Tags :
thermal actuator
Product Attributes :
HTW-TAV01 Series thermal actuators are signed for controlling control valves in HVAC automation systems. The thermal actuator can be controlled by 230Vac/24 Vac on/off control signal or PWM signal.
Product Description
Basic Info.
Model NO.
HTW-TAV-01
Power Consumption
2W
Color
White
Fluid Temperature
0~100ºC
Ambient Temperature
0~60ºC
Protection Class
IP54
Force
95~105n
Operating Current
50mA
Start-up Current
< 300mA ( Max. 2 Min )
Stroke
> 4.5~5.0 mm
Running Time Mounting
Approx.180s ( Close/Open )
Warrenty
1 Year
Transport Package
Carton
Specification
41*31*21CM
Trademark
Neutral/Customized
Origin
China
HS Code
90321000
Production Capacity
500000/Year
Product Description
Thermostatic Heating Valve Thermal Expansion Normally Closed/Open 24V Control
HTW-TAV01 Series thermal actuators are signed for controlling control valves in HVAC automation systems. The thermal actuator can be controlled by 230Vac/24 Vac on/off control signal or PWM signal.
