Home Products Hotowell Products HVAC System Smart Wifi Room Thermostat Heating Controller Work with Amazon Echo Google Home
HVAC System Smart Wifi Room Thermostat Heating Controller Work with Amazon Echo Google Home
HVAC System Smart Wifi Room Thermostat Heating Controller Work with Amazon Echo Google Home HVAC System Smart Wifi Room Thermostat Heating Controller Work with Amazon Echo Google Home HVAC System Smart Wifi Room Thermostat Heating Controller Work with Amazon Echo Google Home HVAC System Smart Wifi Room Thermostat Heating Controller Work with Amazon Echo Google Home HVAC System Smart Wifi Room Thermostat Heating Controller Work with Amazon Echo Google Home

HVAC System Smart Wifi Room Thermostat Heating Controller Work with Amazon Echo Google Home

Product ID : HTW-WF03
Product Attributes :

HTW-WF03 series LED Matrix lighting smart Wifi thermostat is widely used in these environments like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose. It can be used in Electric Underfloor Heating, Water Heating or Water/Gas Boiler systems.

Product Description
HVAC System Smart Wifi Room Thermostat Heating Controller Work with Amazon Echo Google Home

>> General
HTW-WF03 series LED Matrix lighting smart Wifi thermostat is widely used in these environment like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose. It can be used in Electric Underfloor Heating, Water Heating or Water/Gas Boiler systems.



>> Ordering Guide

Please confirm the specific model of this product.
Please read the wiring diagram to identify the model or contact the merchant.
HTW-WF03- **


Code
Application
-3A
Water Heating, 3A, NC+NO+Com output terminals
-16A
Electric Underfloor Heating, 16A, L+N line voltage output terminals
-NV
Water/Gas Boiler, 3A, 1 pair of Non-Voltage output terminals
e.g. HTW-WF03-3A refers to application: Water Floor Heating, 3A, NC+NO+Com output terminals

>> Specifications

Power Supply
95~240Vac, 50/60Hz
Sensor
NTC3950, 10K

Current Load
Fan Relay 5A(-3A-inductive)
Temperature Accuracy
±0.5°C or ±1℉
Valve Relay 3A(1A -inductive)
Set-Point Range
5~35°C
Storage Temp.
-5 ~ 45 °C
Display Temp. Range
5 ~ 99°C
Power Consumption
< 1.5W
Timing Error
< 1%
Housing Material
PC +ABS ( Fireproof)
Installation Box
EU or Standard Electric Box
Protection Class
IP20
Operating Buttons
Capacitive Touch Buttons
Wires on Terminals
Wire 2 x 1.5 mmor 1 x 2.5 mm2

>>Dimensions

Hotowell Top Rated Products



>>FAQs



Q1: What is the unit price?

A: The unit price varies according to different specific requirements, we are more than pleased to quote you the best price once get your specific application. e.g. W/O Modbus, W/O key-card, 2/4 pipe system, W/O customized programming...

Anyway, we are always ready to discuss details with you via Email.

Q2: What is the MOQ, small quantities acceptable?

A: Commonly the MOQ for us is 500pcs, however, we also accept small quantities or Sample orders as starting.

Q3: How is your products' quality and warranty?

A: All of our products meet EU standards, samples are available for quality evaluation; all products are with 18 months warranty.



Q4: Can I print my logo on the products, and customize my own designed packing?

A: 100% YES, but the order quantity shall be over MOQ, or else, extra costs will be charged.

Q5: Do you supply OEM or ODM?

A: Yes, we have strong R&D sources and production ability, and already helping many international companies' OEM/ODM cases with highly positive feedback.

Q6: Why should I buy products from your company?

A: That's really a good question, Quality Products but with Competitive Price, Timely Delivery, Professional and Fast Response...



In a word, WE ARE DIFFERENT, why not just try from the Email...
