Cool/Hot Water Control 2 Way/3 Way Brass Valve Motorized Solenoid Valve
Product ID : V61
Product Tags :
Motorized Zone Valve
Product Attributes :
HTW-V61 series motorized valves(3-wire) are used to control the flow of hot water, chill water in heating, cooling or air-conditioning applications, so as to control room temperature indirectly. It consists of Actuator and Valve Body. The room temperature could be controlled in the set-point through turn-on or turn-off of valve.
Product Description
Cool/Hot Water Control 2 Way/3 Way Brass Valve Motorized Solenoid Valve
HTW-V61 series motorized valves(3-wire) are used to control the flow of hot water, chill water in heating, cooling or air-conditioning applications, so as to control room temperature indirectly. It consists of Actuator and Valve Body. The room temperature could be controlled in the set-point through turn-on or turn-off of valve.
| Model | Rated Power Supply |
| HTW-V61-8503 | AC 220V ± 10%, 50/60HZ |
| HTW-V61-8203 | AC 110V ± 10%, 50/60HZ |
| HTW-V61-8003 | AC 24V ±10%, 50/60HZ |
| Model | Configuration | Kvs | Connection Type |
| HTW-V61-215 | normally closed two-way | 2.0 | G1/2 |
| HTW-V61-220 | normally closed two-way | 3.2 | G3/4 |
| HTW-V61-225 | normally closed two-way | 5.7 | G1 |
| HTW-V61-315 | mixing three-way | 3.2 | G1/2 |
| HTW-V61-320 | mixing three-way | 4.6 | G3/4 |
| HTW-V61-325 | mixing three-way | 4.8 | G1 |
