Hotowell Central Air Conditioner Electric Underfloor Heating Thermostat Smart Wifi Thermostat WF11

Product ID : HTW-WF11

Product Tags :

Product Attributes :

HTW-WF11 series Wifi thermostat is widely used in these environments like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose. It can be used in Electric Underfloor Heating, Water Heating or Water/Gas Boiler systems.

Product Description

Hotowell Central Air Conditioner Electric Underfloor Heating Thermostat Smart Wifi Thermostat WF11

>> General

HTW-WF11 series Wifi thermostat is widely used in these environment like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose. It can be used in Electric Underfloor Heating, Water Heating or Water/Gas Boiler systems.

>> Feature


* Fashion Sense of Science and Technology
* Reduces the costs saving by only heating and cooling your home when it's necessary.
* Allows you to adjust your home's temperature at anytime and anywhere.
* You can set up the whole week's temperature with your personal ideas.
* Extends the life of your HVAC system by alerting you when it's time to perform key maintenance tasks.

>> Specifications

Power Supply	95~240Vac, 50/60Hz	Sensor	NTC3950, 10K
Current Load	3A(-3A, -NV application)	Temperature Accuracy	±0.5°C or ±1℉
Current Load	16A(-16A application)	Set-Point Range	5~35°C
Storage Temp.	-5 ~ 45 °C	Display Temp. Range	5 ~ 99°C
Power Consumption	< 1.5W	Timing Error	< 1%
Housing Material	PC +ABS ( Fireproof)	Installation Box	EU or Standard Electric Box
Wires on Terminals	Wire 2 x 1.5 mm2 or 1 x 2.5 mm2
Protection Class	IP20	Operating Buttons	Capacitive Touch Buttons

>> Typical Wiring

HTW-WF11- **	Smart Wifi Thermostat
	Code	Application
	-3A	Water Heating, 3A, NC+NO+Com output terminals
	-16A	Electric Underfloor Heating, 16A, L+N line voltage output terminals
	-NV	Water/Gas Boiler, 3A, 1 pair of Non-Voltage output terminals
e.g. HTW-WF11-3A refers to application:Water Heating, 3A, NC+NO+Com output terminals
