HVAC System Smart Thermostat Digital Thermostat Fan Coil Thermostat with Modbus Communication
This Thermostat consists of 2 parts:
HTW-EW002 control panel dispalay part
HTW-EW002-RM relay module part
HVAC System Smart Thermostat Digital Thermostat Fan Coil Thermostat with Modbus Communication
>> GeneralNoise-Free Hotel Room FCU Lighting Touch Screen Split Controller Thermostat consists of 2 parts:
HTW-EW002 control panel dispalay part
HTW-EW002-RM relay module part
These 2 parts are connected with 4-pin data wire max. up to 30m, which makes it possible to install the relay module part in a remote place apart from the room, for a noise-free purpose.
HTW-EW002-B is a Touch Screen Split Thermostat Noise-Free Hotel Room Climate Controller application for water installations with fan coils. It is designed as a stand-alone device to operate the fan coil unit of a zone and includes a set of functions for zone occupancy and window position-based climate control.
|
Power Supply
|
100~250Vac, 50/60Hz
|
Installation Box
|
EU or Standard Electric Box
|
|
Current Load
|
3 Speed Fan Relay 5A(3A-inductive)
|
Temperature Sensor
|
NTC, 3950 10K Ω at 25 ºC (77ºF)
|
|
1 Cool Valve Relay 5A(3A-inductive)
|
Operating Temp.
|
5ºC to +35ºC (41ºF to 95ºF)
|
|
|
1 Aux./Heat Valve 5A(3A-inductive)
|
Storage Temp.
|
-20ºC to +85ºC (-4ºF to +185ºF)
|
|
|
1 Lamp Relay 5A(3A-inductive)
|
Operating Humidity (no condensing)
|
10% to 90% RH to 50ºC
|
|
|
Power Consumption
|
< 2W
|
Storage Humidity (no condensing)
|
95% RH to 50ºC
|
|
Housing Material
|
PC +ABS ( Fireproof)
|
Temperature Accuracy
|
± 0.5 ° C or ± 1 ºF
|
|
Wires on Terminals
|
Wire 2 x 1.5 mm² or 1 x 2.5 mm²
|
Set-Point Range
|
5~35°C
|
|
Front Panel Size
|
83x83x16.5mm
|
Relay Module Size
|
110x91x67mm
|
|
Protection Class
|
IP20
|
Electrical Safety
|
Class III
|
|
Inputs
|
Outputs
|
|
1 Digital key-card switch
|
3 Relays, fan coil speed (I, II, III)
|
|
1 Digital window contact
|
1 Relay, chilled water valve
|
|
1 Analog ambient NTC temperature sensor(internal)
|
1 Auxiliary relay
(hot water valve on 4 pipe systems/lighting on 2 pipe systems)
|
|
1 Analog external NTC temperature sensor
|
1 Auxiliary relay for lamp
|
|
|
1 EC Fan DC 0-10V
|
|
|
2 Modulating Valve DC 0/2-10V
|
