Amazon Best Smart Thermostat for Room Heating
--Water/Gas Boiler control with 3A current load and 1 pair of Non-Voltage output terminals
--16A current load thermostat for electric underfloor heating application
--Room temperature controller
--Easily Work with Amazon Echo, Google Home, Tmall Genie,
--Set-Point Range 5~35°C
--Origin: China
-- Lead time: 25 working days
Hotowell Heating Thermostat HTW-HT03 Series.pdf
>> General
HTW-HT03 best smart Amazon Alexa enabled thermostat is widely used in room heating system controls in residential buildings, office buildings, apartments and so on. Now, we are paying more and more attention to the importance of thermal insulation materials for building energy conservation, especially the building envelope. In our daily life, whether it is the cooling capacity of air conditioners or the heat of floor heating, its efficiency and energy consumption are closely related to the heat preservation and energy saving of buildings. The insulation materials in the market can be divided into organic insulation materials (EPS board, XPS board, foamed polyurethane board, etc.) and inorganic insulation materials (glass wool, perlite board, foamed cement, foamed ceramics, etc.). For laying floors In the floor heating system, the ratio of upward to downward heat reaches 3:1, so we need to lay insulation boards at the end of the floor heating to reduce the downward heat loss.
>> Features
* 17 Mainstreaming Languages synchronize in APP(English, Spanish, Russian, Hungarian,Turkey, Hebrew, German, Italian, Japanese, French,Poland, simplified Chinese, traditional Chinese, Holland, Portuguese, Vietnamese, Arabic, Korean)
*Snap-In Easy Installation
*Fit for EU & Standard Junction Electric Box
*Easily Work with Amazon alexa, Google Assitant, IFTTT.
*Group Control in 1 App
*Fashion Sense of Science and Technology
>> Specification
| Power Supply | 95~240Vac, 50/60H | Sensor | NTC3950, 10k |
| Current Load | 3A(-3A, -NV application),16A(-16A application) | Temperature Accuracy | ±0.5°C |
| Set-Point temperature Range | 5~35°C | Storage Temp. | -5 ~ 45 °C |
| Display Temp. Range | 5 ~ 99°C | Power Consumption | < 1.5W |
| Housing Material | PC +ABS ( Fireproof) | Installation Box | EU or Standard Electric Box |
| Wires on Terminals | Wire 2 x 1.5 mm2 or 1 x 2.5 mm2 | Protection Class | IP20 |
>>Wiring Diagram
>> Thermostat Installation
nMake sure the power is OFF! Try turning ON your heating/cooling system by changing the temperature. If you can’t get the system to turn ON in 5 minutes, you’ll know the power is OFF.
nTake off the installation faceplate by grasping and gently pulling, then connect voltage supply/load output/external sensor(if with) wires respectively to appropriate terminals.
nFix the installation plate onto the electric junction box with screws packed in the box.
nFasten the thermostat display part and the installation faceplate through the groove.(Installation process completed)
>> Company Profile
>> FAQs
|
Q1: Do you supply OEM or ODM? |
|
A: Yes, we have strong R&D sources and production ability, and already helping many international companies OEM/ODM cases with highly positive feedback. |
|
Q2: Which payments are acceptable? |
|
A: We accept T/T,Paypal,Western Union. |
|
Q3: How fast can I get the quotation? |
|
A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us +86 0592 6538262 or tell us in your email so that we will regard your inquiry priority. |
|
Q4: What’s your production time? |
|
A:Usually production time is 15 to 20 days for quantity below 5,000pcs.
|
