T6861 Digital Smart Thermostat Air Conditioner Fan Coil Room Thermostat
T6861 Digital Smart Thermostat Air Conditioner Fan Coil Room Thermostat T6861 Digital Smart Thermostat Air Conditioner Fan Coil Room Thermostat T6861 Digital Smart Thermostat Air Conditioner Fan Coil Room Thermostat T6861 Digital Smart Thermostat Air Conditioner Fan Coil Room Thermostat T6861 Digital Smart Thermostat Air Conditioner Fan Coil Room Thermostat

T6861 Digital Smart Thermostat Air Conditioner Fan Coil Room Thermostat

Product ID : T6861
Product Tags : Fan coil thermostatRoom thermostatThermostatsmart thermostat
Product Attributes :

This digital thermostats are designed for application of 3-speed fan and valves in fan coil system. This model with total the same functions with Honeywell raw model T6861.

Product Description
T6861 Digital Smart Thermostat Air Conditioner Fan Coil Room Thermostat
Product Description

>> General





This digital thermostats are designed for application of 3-speed fan and valves in fan coil system.
This model with total the same functions with Honeywell raw model T6861.





>> Specification

Power supply
110(+/-10%)VAC,220(+10%,-15%)VAC
Frequency
50/60HZ
Control algorithm
Pl, On/off output
Accuracy
+/- 1°C at 21 °C
Rating capacity
For 220V power supply :4( 2)A for fan load, 2(1)A for zone valve
Cycle times
100000
Setpoint range
10-32°C
Display range
0-37°C
Installation
Installed on 86x86mm junction box or US2X4 inch
Protection Class
P20
Environmental
Operation temperature-18~49°C
Conditions
Shipping temperature -35~65°C, Relative humidity 5-90%

>>Application

>> Model Summary
HTW-51-1000
Horizontal/Vertical
White Frame Backlight
Time on/off
2-pipe/4-pipe
Power supply
Energy Saving
Ventilation
Manual/Automatic Fan
Remote Sensor
H2WB
Horizontal
Blue
Y
2\4
220
Y
Y
Y
Y
V2WB
Vertical
Blue
Y
2\4
220
Y
Y
Y
Y
H2WG
Horizontal
Green
Y
2\4
220
Y
Y
Y
Y
V2WG
Vertical
Green
Y
2\4
220
Y
Y
Y
Y
H1WB
Horizontal
Blue
Y
2\4
110
Y
Y
Y
Y
V1WB
Vertical
Blue
Y
2\4
110
Y
Y
