24VAC T6865 Digital White Backlight Fan Coil Thermostat Modulating Valve Control

Product ID : T6865

Product Tags : Fan coil thermostat

Product Attributes :

T6865 digital thermostats are designed for application of 3-speed fan and modulating valves in fan coil system. This model include Blue or Green color choice with Horizontal shape. With power 24vac 50/60Hz for modulating valve.Our this model with the same functions with Honeywell T6865, include choice of Remote sensor or Remote set-back.

Product Description

24Vac T6865 Digital White Backlight Fan Coil Thermostat Modulating Valve Control

>> General

T6865 digital thermostats are designed for application of 3-speed fan and modulating valves in fan coil system. This model include Blue or Green color choice with Horizontal shape. With power 24vac 50/60Hz for modulating valve.Our this model with the same functions with Honeywell T6865, include choice of Remote sensor or Remote set-back.

>> Features

• 2-pipe cool only/heat only/manual changeover and
• 4-pipe manual or automatic changeover
• Ventilation mode
• Manual or automatic 3-speed fan control
• Water valve control
• Fan speed can be selected to automatic or manual
• 3-speed control mode.
• In ventilation mode, fan only support manual speed control.

24VAC T6865 Digital White Backlight Fan Coil Thermostat Modulating Valve Control

>>Technical Data

Power supply	24 (+/-10%) VAC
Frequency	50Hz
Modulating output	DC 0......10V, Support VC7900 series actuators
Fan load rating	230(+/-10%)VAC, 4(2)A
Relay life	100,000 times
Wiring	Max 16AWG
Sensing element	10K (@25ºC) NTC
Accuracy	+/-1ºC at 21ºC
Setpoint range	10~32ºC
Display range	0~37ºC
Protection Class	IP20 Operation temperature

HTW-51-1000	Horizontal/Vertical	White Frame Backlight	Time on/off	2-pipe/4-pipe	Power supply	Energy Saving	Ventilation	Manual/Automatic Fan	Remote Setback
T6865H2WB	Horizontal	Blue	Y	2	24	Y	Y	Y	Y
T6865H2WG	Horizontal	Green	Y	2	24	Y	Y	Y	Y
