0-10V Modulating Output Smart Room Thermostat for Fcu System
Product ID : HTW-WF03-FC
Product Tags :
Fan coil thermostatRoom thermostatThermostatWifi thermostatair conditioner thermostathotel thermostatmodbus thermostat
Product Attributes :
HTW-WF03-FC series smart wifi thermostat is widely used in these environment like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose.
Product Description
0-10V Modulating Output Smart Room Thermostat for FCU System
>> General
HTW-WF03-FC series smart wifi thermostat is widely used in these environment like Homes, Residential buildings, Schools, Hotels, Hospitals, Offices and etc. to main an ideal room temperature purpose.
>> Features
--47 Mainstreaming Language
--Customized OEM Logo
--Work with Amazon Echo, Google Home, Tmall Genie, IFTTT
--Easy Installation
--Black/ White colors
--Fit for EU & Standard Junction Electric Box
>> Specification
>> Features
--47 Mainstreaming Language
--Customized OEM Logo
--Work with Amazon Echo, Google Home, Tmall Genie, IFTTT
--Easy Installation
--Black/ White colors
--Fit for EU & Standard Junction Electric Box
>> Specification
| Power Supply | 95~240Vac, 50/60Hz | Sensor | NTC3950, 10K |
| Current Load | Fan Relay 5A(3A-inductive) | Temperature Accuracy | ±0.5°C or ±1ºF |
| Valve Relay 3A(1A-inductive) | Set-Point Range | 5~35°C | |
| Storage Temp. | -5 ~ 45 °C | Display Temp. Range | 5 ~ 99°C |
| Power Consumption | < 1.5W | Timing Error | < 1% |
| Housing Material | PC +ABS ( Fireproof) | Installation Box | EU or Standard Electric Box |
| Wires on Terminals | Wire 2 x 1.5 mm2 or 1 x 2.5 mm2 | ||
| Protection Class | IP20 | Operating Buttons | Capacitive Touch Buttons |
>> Dimensions and Display
