Smart wireless & wifi control floor heating thermostat
Smart wireless & wifi control floor heating thermostat Smart wireless & wifi control floor heating thermostat Smart wireless & wifi control floor heating thermostat Smart wireless & wifi control floor heating thermostat Smart wireless & wifi control floor heating thermostat

Smart wireless & wifi control floor heating thermostat

Product ID : HTW-31-WKT13-WF
Product Attributes :

This surface-mounted radio thermostat has been developed to be able to switch electric and conventional heating systems on and off using a set temperature and time.

Product Description


Wireless wifi smart thermostat  HTW-31-WKT13-WF.pdf

 >> General

This surface-mounted radio thermostat has been developed to be able to switch electric and conventional heating systems on and off using a set temperature and time.


 >> Feature

*  Large display can be clearly read with the background lighting.

*  Easy to fit thermostat and receiver.

*  Five buttons make it easy to use.

*  4 periods of each day programmable

*  The display shows the set temperature as well as the measured temperature, time.

*  Temperature display in degrees Celsius.

*  The thermostat is supplied with a wall-fixing frame, base and a very compact receiver (surface-mounted).


 >> Technical Data

Thermostat operating voltage:               2 x AA1.5 V, alkaline batteries.

Backup storage:                                     EEPROM

Receiver operating voltage:                   230 VAC, 50/60 Hz

Maximum voltage / (ohmic) load:            250 VAC/10 A.

Frequency:                                             868 MHz

Channel selection:                                  By programming the thermostat and the receiver.

Switching options:                                   7day, 4 periods each day.

Receiver switch contacts:                       NO and NC.

Temperature settings:                            5°C ~ 35°C, 0.5°C increments.

Accuracy:                                               +/- 0.5°C

Thermostat dimensions:                        Surface mounted, 135mm x 87.5 mm x 23.2mm.

Receiver dimensions:                            Surface mounted, 86mm x 86 mm

Color:                                                    White

IP protection rating:                               20.

Certification:                                          CE, Rohs, R&TTE

>> Display and Buttons

wireless wifi smart thermostat Display and Buttons.png

 >> Wiring Diagram

Wiring Diagram.png


Hotowell manufacturing capacity.jpg
