Noise-Free Hotel Room FCU Lighting Touch Screen Split Controller Thermostat
Noise-Free Hotel Room FCU Lighting Touch Screen Split Controller Thermostat Noise-Free Hotel Room FCU Lighting Touch Screen Split Controller Thermostat Noise-Free Hotel Room FCU Lighting Touch Screen Split Controller Thermostat Noise-Free Hotel Room FCU Lighting Touch Screen Split Controller Thermostat Noise-Free Hotel Room FCU Lighting Touch Screen Split Controller Thermostat

Noise-Free Hotel Room FCU Lighting Touch Screen Split Controller Thermostat

Product ID : HTW-61-EW001-B
Product Attributes :

Noise-Free Hotel Room FCU Lighting Touch Screen Split Controller Thermostat consists of 2 parts:

HTW-61-EW001-B control panel display part

HTW-61-EW001-RM relay module part

These 2 parts connected with 4-pin data wire max. up to 30m, which makes it possible to install the relay module part to a remote place apart from the room, for a noise-free purpose.

Product Description


Compressed-HTW-61-EW001-B-Print Manual 2page version-HTW-61-EW001-B.pdf

 >> General

Noise-Free Hotel Room FCU Lighting Touch Screen Split Controller Thermostat consists of 2 parts:

HTW-61-EW001-B control panel dispalay part

HTW-61-EW001-RM relay module part

These 2 parts conected with 4-pin data wire max. up to 30m, which makes it possible to install the relay module part to a remote place apart from the room, for a noise-free purpose.


HTW-61-EW001-B is a Touch Screen Split Thermostat Noise-Free Hotel Room Climate Controller application for water installations with fan coils. It is designed as a stand-alone device to operate the fan coil unit of a zone and includes a set of functions for zone occupancy and window position based climate control.

A high level of comfort and appropriate climate control to ensure maximum energy savings are thus provided.
The device is a compact unit that includes a large backlit display screen, a built in temperature sensor, pushbuttons on the front panel, and inputs and outputs built on split remote relay module for room control.

This Split Thermostat Climate Controller includes two parts:

HTW-61-EW001-B
HTW-61-EW001-RM

These two parts are communicated via 4-wire connections:
-GND
-12V
-TXD
-RXD
It provides a totally Noise-Free application due to its remoted relay module.


>>Features

-Touch Screen Display
-60mm Standard Installation Hole Distance
- Wide, blue backlit LCD, 65 × 59 (mm)

- Front panel built in pushbuttons: +T/-T/Fan speed/On-Off

- Front panel built in temperature sensor

- Change Over-HEAT/COOL

- Configurable for 2 pipe / 4 pipe systems

- Selectable temperature units (ºC/ºF)

- Configurable max/min/economy temperature setpoints

- Keycard switch contact occupancy monitoring for energy saving

- Configurable keycard switch input: keycard switch/lighting

- Configurable fan coil: 3 speeds / 1 speed

- Speed 1 configurable as blocked or unblocked on zero demand

- Economy mode Heat/Cool temperature setpoint Heat/Cool dead band

- Delayed switching to Economy when card is removed

- Automatic device startup after loss of power

- Configurable NO/NC valve outputs

- Connfigurable anti-humidity frequency:10/30,5/30,5/60

- Noise-Free application

>>Device Inputs and Outputs
Inputs:

1 Digital, keycard switch contact / lighting auxiliary contact

1 Digital, window contact

1 Analog, ambient temperature external sensor

1 Temperature sensor, built in on device front panel



Outputs:

3 Relays, fan coil speed (I,II,III)

1 Relay, chilled water valve

1 Auxiliary relay (hot water valve on 4 pipe systems / lighting on 2 pipe

systems)

1 Auxiliary relay for lamp

>>Wiring Diagram


>> Application
