Hotowell EC Fan Motor Controller-HTW-61-D.A series
Hotowell EC Fan Motor Controller-HTW-61-D.A series Hotowell EC Fan Motor Controller-HTW-61-D.A series Hotowell EC Fan Motor Controller-HTW-61-D.A series Hotowell EC Fan Motor Controller-HTW-61-D.A series Hotowell EC Fan Motor Controller-HTW-61-D.A series

Hotowell EC Fan Motor Controller-HTW-61-D.A series

Product ID : HTW-61-D.A
Product Attributes :

This series thermostat application is designed for room climate control at hotels, offices and homes with water and fan coil installations.

-3D1D includes 3 load digital ON/OFF fan speed outputs and 1 load digital ON/OFF valve output;

-1A1D includes 1 load analogue EC fan motor output and 1 load digital ON/OFF valve output;

-1A1A includes 1 load analogue EC fan motor output and 1 load analogue valve output;

The device includes a built in temperature sensor on its front panel for room temperature measurement, and features an advanced control algorithm for fan coil speed and valve position control.

The device includes a simple configuration menu that allows configuring up to 28 parameters. The unit can thus be adapted to the requirements of each installation


Product Description


Hotowell EC Fan Motor Controller-HTW-61-D.A series.pdf

 >> General

This series thermostat application is designed for room climate control at hotels, offices and homes with water and fan coil installations.

-3D1D includes 3 load digital ON/OFF fan speed outputs and 1 load digital ON/OFF valve output;

-1A1D includes 1 load analogue EC fan motor output and 1 load digital ON/OFF valve output;

-1A1A includes 1 load analogue EC fan motor output and 1 load analogue valve output;

The device includes a built in temperature sensor on its front panel for room temperature measurement, and features an advanced control algorithm for fan coil speed and valve position control.

The device includes a simple configuration menu that allows configuring up to 28 parameters. The unit can thus be adapted to the requirements of each installation

>>Features

-100~240Vac, 50/60Hz

-Touch Screen Display
-60mm Standard Installation Hole Distance
- Change Over-HEAT/COOL

- Configurable for 2 pipe / 4 pipe systems

- Selectable temperature units (ºC/ºF)

>>Wiring Diagram

HTW-61-D.A-5 wiring.jpg
